Front Part for Cooling Jacket Advanced incl. Pipe Flange
.
- Required for all Optris high-performance pyrometers in Cooling Jacket Advanced
- Compatible to CTlaser, CSlaser, CTvideo, CSvideo, and CSvision
- Easy assembly
From 150,00€
Product Description
Every Optris pyrometer mounted in a Cooling Jacket Advanced requires a front part. Suited for all Optris High-Performance pyrometers, this robust unit ensures precise temperature measurements by keeping the pyrometer enclosed. The modular design allows easy integration and maintenance. Equipped with optional protective windows and air purge systems, it safeguards against contaminants, ensuring reliable readings. A pipe flange option is available for furnace installations.
Specification
General Specifications
- Operating temperature: 0 °C to 60 °C (up to 315 °C with water cooling)
- Storage temperature: 0 °C to 60 °C
- Material: Anodized aluminum
- Weight: 120 g
- Size: OD 84 mm
Downloads
FAQs
I already have a Cooling Jacket Advanced for a CSvideo. Now, I want to change the CSvideo to a CSvision. Do I need a new part?
Don’t worry, the Front Part is suitable for all Optris High performance pyrometers. It’s a straightforward process of replacing the pyrometer.
What is the Cooling Jacket Advanced used for?
The Cooling Jacket Advanced protects Optris pyrometers in high-temperature environments, ensuring accurate temperature measurements.
Which pyrometers are compatible with this front part in the Cooling Jacket Advanced?
It is compatible with all Optris High-Performance pyrometers, including CTlaser, CSlaser, CTvideo, CSvideo, and CSvision models.
How does the front part of the Cooling Jacket Advanced contribute to its performance?
The front part keeps the pyrometer in place and enclosed, facilitating precise temperature measurements and protecting the device from environmental hazards.
Can the Cooling Jacket Advanced be installed on a pipe looking into a furnace?
A pipe flange option is available for such installations, ensuring optimal protection and performance.
Are there any optional accessories available for the Cooling Jacket Advanced?
Optional accessories include protective windows and air purge systems to safeguard against contaminants and environmental hazards.
Scope of Supply
- 1x front part for Cooling jacket advanced and Optris high performance pyrometers
- Mounting screws
